Detailed Description

This constrains the slave nodes to be kinematically constrained to the master node.

Definition at line 45 of file kinematic_coupling.h.

#include <kinematic_coupling.h>

Inheritance diagram for MAST::KinematicCoupling:

[legend]

Collaboration diagram for MAST::KinematicCoupling:

[legend]

Public Member Functions
	KinematicCoupling (MAST::SystemInitialization &sys_init)

virtual	~KinematicCoupling ()

void	add_dof_constraints_to_dof_map ()
	initializes the dof constraint rows in the DofMap object associated with the system. More...

void	add_master_and_slave (const std::set< const libMesh::Node *> &master, const libMesh::Node &slave, bool constrain_rotations)
	Constrain the slave node to the specified set of master nodes. More...

void	add_master_and_slave (const std::vector< std::pair< const libMesh::Node , std::set< const libMesh::Node >>> &couplings, bool constrain_rotations)
	provides a vector of the pair of slave and set of master nodes. More...

virtual void	get_constraint_rows (std::vector< std::tuple< libMesh::dof_id_type, libMesh::DofConstraintRow, Real >> &constrs)
	Provides the vector of constraints and right-hand-side value pairs to be added to the system. More...

Public Member Functions inherited from MAST::DoFCouplingBase
	DoFCouplingBase (MAST::SystemInitialization &sys_init)

virtual	~DoFCouplingBase ()

Protected Attributes
bool	_initialized

std::map< const libMesh::Node , const MAST::KinematicCouplingConstraint >	_slave_node_constraints

Protected Attributes inherited from MAST::DoFCouplingBase
MAST::SystemInitialization &	_system_init

Constructor & Destructor Documentation

◆ KinematicCoupling()

MAST::KinematicCoupling::KinematicCoupling ( MAST::SystemInitialization & sys_init )

Definition at line 31 of file kinematic_coupling.cpp.

◆ ~KinematicCoupling()

MAST::KinematicCoupling::~KinematicCoupling ( )

virtual

Definition at line 38 of file kinematic_coupling.cpp.

Member Function Documentation

◆ add_dof_constraints_to_dof_map()

void MAST::KinematicCoupling::add_dof_constraints_to_dof_map ( )

initializes the dof constraint rows in the DofMap object associated with the system.

Definition at line 84 of file kinematic_coupling.cpp.

◆ add_master_and_slave() [1/2]

void MAST::KinematicCoupling::add_master_and_slave	(	const std::set< const libMesh::Node *> &	master,
		const libMesh::Node &	slave,
		bool	constrain_rotations
	)

Constrain the slave node to the specified set of master nodes.

A geometric relation is used to compute the weights for each master dof. If constrain_rotations is true then the rotations of the slave nodes are constrained to those of the master nodes. Otherwise, the constraint acts as a pinned connection.

Definition at line 65 of file kinematic_coupling.cpp.

◆ add_master_and_slave() [2/2]

void MAST::KinematicCoupling::add_master_and_slave	(	const std::vector< std::pair< const libMesh::Node , std::set< const libMesh::Node >>> &	couplings,
		bool	constrain_rotations
	)

provides a vector of the pair of slave and set of master nodes.

Definition at line 53 of file kinematic_coupling.cpp.

◆ get_constraint_rows()

void MAST::KinematicCoupling::get_constraint_rows ( std::vector< std::tuple< libMesh::dof_id_type, libMesh::DofConstraintRow, Real >> & constrs )

virtual

Provides the vector of constraints and right-hand-side value pairs to be added to the system.

Implements MAST::DoFCouplingBase.

Definition at line 106 of file kinematic_coupling.cpp.

Member Data Documentation

◆ _initialized

bool MAST::KinematicCoupling::_initialized

protected

Definition at line 92 of file kinematic_coupling.h.

◆ _slave_node_constraints

std::map<const libMesh::Node*, const MAST::KinematicCouplingConstraint*> MAST::KinematicCoupling::_slave_node_constraints
